S2001/S3001 Industrial UPS
.png)
Ac/ac Single Phase Or Three Phase Output Ups
SATRON S2001/S3001 series are Industrial, Heavy Duty ON-LINE Double Conversion UPS designed to supply critical AC Loads with stabilised continues voltage.Products can be easily customized depending on the peculiar Customer request. Transformer for AC/DC galvanic separation and static and manual By-Pass is included Applications: Features: Main Options: Single-line Diagram Size (kVA) cosφ= 0.8 5 10 15 20 25 5 10 15 20 30 40 50 AC Input Rated Voltage Vac 380/400/415Vac +/-10% 3Ph 50/60Hz (other as option) Power Factor 0,8 @ full load THD THD ≤ 30 % typ. AC Output Output Voltage Vac 230 Vac 1Ph 50/60Hz (other as option)) By pass input voltage 230 Vac 1Ph +/-10% (other as option)) Harmonic Distortion <2 % with linear load/ <5% with nonlinear load Crest factor 3:1 Overload 105% permanent - 125 % for 10 min. - 150 % for 1min. - 200 % for 100ms Static Stability +/- 1% Dynamic Stability +/-5 % (80% load step) with recovery to 2 % in 40ms DC Link DC Voltage 110Vdc (90 - 150 ) 220Vdc (180 - 300) Battery voltage Floating: 2.27 (VRLA), 2.2÷2.3 (VLA), 1.4÷1.5 (Ni-Cd) V/cell Boost: 2.4÷2.45 (VLA), 1.5÷1.65 (Ni-Cd) V/cell Equalizing: up to 2.35 (VRLA), up to 2.7 (VLA), up to 1.7 (Ni-Cd) V/cell Charging current 4 8 12 16 20 2 4 6 8 12 16 20 Control & Signalisation Microprocessor High Performance 8-Bit Microcontroller with Advanced RISC Architecture LCD Pane Backlit graphic LCD for Meters, Alarm/Status messages, History events & Parameters Settings (password protected) Signalling LED Inverter normal (green), Inverter fault (red), Rectifier normal (green), Rectifier fault (red) Acoustic Signa Buzzer MIMIC Panel Principle block diagram of the UPS with 9 integrated LED Volt free signalling contacts AC input supply failure, Rectifier failure, DC voltage LOW/HI, Battery discharging, Battery disconnected, Inverter failure, Inverter overload, Inverter over temperature, AC output voltage LOW/HI, Ventilation failure, DC hearth fault (option) Environmental conditions Operating Temperature 0°C + 40°C not condensing Storage Temperature : -20°C to +70°C Relative Humidity ≤ 95% a 40°C Altitude ≤ 1000 m without derating Audible Noise < 65 –70 dB (A) at 1 m Efficiency At Full Load ≥ 88% MTBF 140.000 hr at 30 °C Mechanical Characteristics Cabinet Free standing, floor mounting, Steel sheet Enclosure - Front door with handle (double rods) Steel thickness Frame 2mm, Door & Sides 1.5mm, Rear & Roof 1.2mm Cooling method Cabinet: Natural - Semiconductor heat sink: Fan assisted (temperature-controlled) Access Front door Cable entry From bottom / Other on request Degree of protection IP20 / Other on request Painting / Colour Epoxy-polyester thermosetting powder coating / RAL 7035 Dimensions (mm) W 800 1000 1000 1400 1600 800 800 1000 1200 1400 1600 1800 D 800 800 800 800 800 800 800 800 800 800 800 800 H 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900 Standards Size (kVA) cosφ= 0.8 5 10 20 30 40 10 20 30 40 50 60 80 AC Input Rated Voltage Vac 380/400/415Vac +/-10% 3Ph 50/60Hz (other as option) Power Factor 0,8 @ full load THD THD ≤ 30 % typ. AC Output Output Voltage Vac 400Vac 3Ph+N, 50-60Hz +/- 0.001 free running (other as option) By pass input voltage 380/400/415Vac +/-10% 3Ph +N (other as option) Harmonic Distortion <2 % with linear load/ <5% with nonlinear load Crest factor 3:1 Overload 105% permanent - 125 % for 10 min. - 150 % for 1min. - 200 % for 100ms Static Stability +/- 1% Dynamic Stability +/-5 % (80% load step) with recovery to 2 % in 40ms DC Link DC Voltage 110Vdc (90 - 150 ) 220Vdc (180 - 300) Battery voltage Floating: 2.27 (VRLA), 2.2÷2.3 (VLA), 1.4÷1.5 (Ni-Cd) V/cell Boost: 2.4÷2.45 (VLA), 1.5÷1.65 (Ni-Cd) V/cell Equalizing: up to 2.35 (VRLA), up to 2.7 (VLA), up to 1.7 (Ni-Cd) V/cell Charging current 4 8 12 16 20 4 8 12 16 20 24 30 Control & Signalisation Microprocessor High Performance 8-Bit Microcontroller with Advanced RISC Architecture LCD Pane Backlit graphic LCD for Meters, Alarm/Status messages, History events & Parameters Settings (password protected) Signalling LED Inverter normal (green), Inverter fault (red), Rectifier normal (green), Rectifier fault (red) Acoustic Signa Buzzer MIMIC Panel Principle block diagram of the UPS with 9 integrated LED Volt free signalling contacts AC input supply failure, Rectifier failure, DC voltage LOW/HI, Battery discharging, Battery disconnected, Inverter failure, Inverter overload, Inverter over temperature, AC output voltage LOW/HI, Ventilation failure, DC hearth fault (option) Environmental conditions Operating Temperature 0°C + 40°C not condensing Storage Temperature : -20°C to +70°C Relative Humidity ≤ 95% a 40°C Altitude ≤ 1000 m without derating Audible Noise < 65 –70 dB (A) at 1 m Efficiency At Full Load ≥ 88% MTBF 140.000 hr at 30 °C Mechanical Characteristics Cabinet Free standing, floor mounting, Steel sheet Enclosure - Front door with handle (double rods) Steel thickness Frame 2mm, Door & Sides 1.5mm, Rear & Roof 1.2mm Cooling method Cabinet: Natural - Semiconductor heat sink: Fan assisted (temperature-controlled) Access Front door Cable entry From bottom / Other on request Degree of protection IP20 / Other on request Painting / Color Epoxy-polyester thermosetting powder coating / RAL 7035 Dimensions (mm) W 800 1000 1600 1600 1800 800 1200 1400 1600 1800 1800 2000 D 800 800 800 800 800 800 800 800 800 800 800 800 H 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900 Standards
S3001 UPS 3Ph/3Ph Technical Specifications
